Descrizione
SPECIFICATIONS
1
Engine
Engine Type
Zongshen, Single-cylinder, 4-stroke, Oil cooling, Manual clutch, 5 gears
Displacement
292.4cc
Bore*Stroke
78mm*61.2mm
Compression Ratio
11:1
Max. Power
19.3kw/8500rpm
Max. Torque
20N.m/5500rm
Fuel System
EFI
Starting
Electric
Transmission
Chain (13T-47T 530H#)
Ignition
CDI
2
Chasis
Frame
Professional design and processed by KAYO
Front shock
L=375mm Adjustable
Rear shock
L=380mm Adjustable
Front Braking
Disc Brake
Rear Braking
Disc Brake
Front Wheel Rim
Steel 10*5.5 AT-4/110 90
Rear Wheel Rim
Steel 9*8.0 AT-4/110 90
Front Tyre
10'' AT20*7-10 CST TYRE
Rear Tyre
9'' AT19*10-9 CST TYRE
3
Dimensions & Capacities
Vehicle Size
1660*1155*1030mm
Wheelbase
1140mm
Seat Height
790mm
Ground Clearance
115mm
Dry Weight
168 kg
Fuel Capacity
5.5L
Packing Size
1640*1140*810 mm
